Why Choose the MRCOOL VersaPro Heat Pump Condenser?
The MRCOOL VersaPro 36K BTU 3.0 Ton Heat Pump Condenser ONLY is the outdoor unit of the MRCOOL VersaPro central ducted heat pump system. Delivering 36,000 BTU of cooling and heating capacity, this condenser pairs with the MRCOOL VersaPro Air Handler to create a complete, high-efficiency central ducted heat pump system. Using next-generation R-454B refrigerant with a significantly lower Global Warming Potential (GWP) than R-454B, the VersaPro condenser is designed for residential and light commercial applications where efficiency, reliability, and environmental responsibility are priorities. AHRI certified when paired with compatible VersaPro air handlers.
About the MRCOOL VersaPro 36K BTU 3.0 Ton Heat Pump Condenser ONLY
The MRCOOL VersaPro Central Ducted Heat Pump Condenser is an inverter-driven outdoor unit engineered for year-round heating and cooling performance. The variable-speed compressor technology allows the system to modulate capacity based on demand, delivering superior energy efficiency compared to single-stage systems. The heavy-gauge galvanized steel cabinet with baked enamel finish provides corrosion resistance for outdoor installation. The condenser features a factory-installed service valves, a high-efficiency scroll compressor, and a weather-resistant electrical compartment. This 36K BTU (3.0 Ton) condenser is designed to work exclusively with the MRCOOL VersaPro Air Handler in a split-system configuration. AHRI certification must be verified for your specific condenser + air handler combination at ahridirectory.org.
📊 Technical Specifications
| Specification | Value |
|---|---|
| Brand | MRCOOL |
| Model / SKU | MVP-36-HP-C-230-00 |
| Series | VersaPro® Central Ducted Condenser |
| Type | Heat Pump Condenser ONLY |
| BTU Capacity | 36,000 BTU |
| Tonnage | 3.0 Ton |
| SEER2 Rating | 14.3 |
| HSPF2 Rating | 7.5 |
| Voltage | 208-230V |
| Refrigerant | R-454B |
| Weight | 115.0 lbs (52.2 kg) |
| AHRI Certification | AHRI certified when paired with compatible VersaPro air handlers |
💡 Pro Installation & Usage Tips
- Always verify AHRI certification for your specific condenser + air handler combination before installation.
- This condenser requires a compatible MRCOOL VersaPro air handler — it is not a standalone unit.
- Install the condenser on a level pad with adequate clearance on all sides per manufacturer specifications.
- Use the correct line set size for your BTU capacity and run length — consult the installation manual for specifications.
- Register your product within 30 days of installation to activate the full 10-year parts warranty (when registered by a licensed HVAC contractor).
❓ Frequently Asked Questions
🔗 Compatible Accessories
Check the accessories you need and see your estimated total below.
🎯 Warranty & Registration
✅ AHRI Certification: AHRI certified when paired with compatible VersaPro air handlers. Verify at ahridirectory.org. | Refrigerant: R-454B | Electrical: 208-230V
