MRCOOL DIY 5th Gen 6-Zone 55K BTU OuttaSight Ceiling Cassette System (6K+6K+6K+9K+9K+9K) — Complete Bundle

MRCOOL

No reviews yet Write a Review
SKU:
HVP-D5-6Z-55K-CC-6-6-6-9-9-9
$8,815.00 ex. Tax
MRCOOL DIY 5th Gen 6-Zone 55K BTU OuttaSight Ceiling Cassette System (6K+6K+6K+9K+9K+9K) — Complete Bundle
Condition:
New
$8,815.00 ex. Tax
41 people looking at this.

Description

MRCOOL DIY 5th Gen 6-Zone OuttaSight Ceiling Cassette System — 55K BTU

The perfect ceiling-mounted solution for commercial spaces, open floor plans, and rooms where wall space is limited. Each OuttaSight cassette mounts flush into a standard 2×2 ft ceiling grid for a clean, professional appearance.

6 Independent Zones 55K BTU Condenser R-454B Refrigerant Quick Connect DIY Built-in Wi-Fi Total: 791 lbs

What's Included in This Bundle

Component MRCOOL SKU Qty BTU Weight
Multi-Zone Outdoor Condenser DIY-55-HP-WIF25-O 1 55,000 BTU 263.37 lbs
Zone 1 — OuttaSight Ceiling Cassette Air Handler DIYCASSETTE06HP-230D25-O 1 6,000 BTU 88 lbs
Zone 2 — OuttaSight Ceiling Cassette Air Handler DIYCASSETTE06HP-230D25-O 1 6,000 BTU 88 lbs
Zone 3 — OuttaSight Ceiling Cassette Air Handler DIYCASSETTE06HP-230D25-O 1 6,000 BTU 88 lbs
Zone 4 — OuttaSight Ceiling Cassette Air Handler DIYCASSETTE09HP-230D25-O 1 9,000 BTU 88 lbs
Zone 5 — OuttaSight Ceiling Cassette Air Handler DIYCASSETTE09HP-230D25-O 1 9,000 BTU 88 lbs
Zone 6 — OuttaSight Ceiling Cassette Air Handler DIYCASSETTE09HP-230D25-O 1 9,000 BTU 88 lbs
TOTAL SYSTEM WEIGHT 791.4 lbs (358.96 kg)

Ordering Guide — What to Order from MRCOOL

To fulfill this bundle, order the following MRCOOL SKUs:

  • DIY-55-HP-WIF25-O × 1 — 55K BTU Multi-Zone Condenser
  • DIYCASSETTE06HP-230D25-O × 1 — 6K BTU OuttaSight Ceiling Cassette Air Handler
  • DIYCASSETTE06HP-230D25-O × 1 — 6K BTU OuttaSight Ceiling Cassette Air Handler
  • DIYCASSETTE06HP-230D25-O × 1 — 6K BTU OuttaSight Ceiling Cassette Air Handler
  • DIYCASSETTE09HP-230D25-O × 1 — 9K BTU OuttaSight Ceiling Cassette Air Handler
  • DIYCASSETTE09HP-230D25-O × 1 — 9K BTU OuttaSight Ceiling Cassette Air Handler
  • DIYCASSETTE09HP-230D25-O × 1 — 9K BTU OuttaSight Ceiling Cassette Air Handler

Technical Specifications

Bundle SKUHVP-D5-6Z-55K-CC-6-6-6-9-9-9
SeriesMRCOOL DIY 5th Generation
Indoor Unit TypeOuttaSight® Ceiling Cassette (One-Way Airflow)
Number of Zones6
Condenser Capacity55,000 BTU
Zone Capacities6K BTU, 6K BTU, 6K BTU, 9K BTU, 9K BTU, 9K BTU
RefrigerantR-454B (Pre-Charged Quick Connect)
Voltage208-230V / 60Hz / 1Ph
Ceiling Opening Required23.5" × 23.5" per unit (standard 2×2 ft grid)
ConnectivityBuilt-in Wi-Fi, MRCOOL Smart Home App, Wireless Remote
Total System Weight791.4 lbs (358.96 kg)
Warranty7-Year Compressor / 5-Year Parts (registered)
AHRI CertifiedYes — verify at ahridirectory.org

Installation & Product Tips

  • Ceiling Access Required: Each OuttaSight unit requires above-ceiling access for mounting, line set routing, and condensate drain connection. Plan your installation carefully before ordering.
  • Condensate Drain: Each cassette unit requires a condensate drain line. Route to a floor drain or use a condensate pump if gravity drainage is not available.
  • Ceiling Grid Compatibility: The OuttaSight mounts in a standard 2×2 ft suspended ceiling grid. For drywall ceilings, a custom framed opening is required.
  • Line Set Length: Each zone requires its own line set. Maximum line set length is 75 ft per zone. Order the correct length for each zone separately.
  • Register Your Warranty: Register all components at mrcool.com within 30 days of installation to activate the 7-year compressor and 5-year parts warranty.

Frequently Asked Questions

This system uses MRCOOL DIY 5th Gen OuttaSight® Ceiling Cassette air handlers. These units mount flush into a standard ceiling grid (2×4 ft tile space) and deliver conditioned air in a single direction along the ceiling. They are ideal for commercial spaces, offices, retail environments, and open-plan areas where wall space is limited.
Yes — the MRCOOL DIY 5th Gen OuttaSight uses pre-charged Quick Connect line sets, eliminating the need for a refrigerant technician for the refrigerant connection. However, ceiling cassette installation requires ceiling access, electrical work, and condensate drain routing. We recommend a qualified contractor for the mechanical installation.
This 6-Zone system has a total indoor capacity of 45,000 BTU (6K, 6K, 6K, 9K, 9K, 9K) connected to a 55K BTU outdoor condenser.
This system uses R-454B refrigerant, the next-generation low-GWP refrigerant replacing R-410A. The Quick Connect line sets are pre-charged from the factory, so no refrigerant handling is required during installation.
Each MRCOOL OuttaSight Ceiling Cassette requires a 23.5" × 23.5" ceiling opening (fits a standard 2×2 ft ceiling grid). The unit mounts above the ceiling tile with a decorative grille panel visible from below.
No — this bundle is configured with ceiling cassette (OuttaSight) air handlers only. If you need a mix of cassette and wall mount units, Contact us at hvacprosales.com/contact-us/ and we will build a custom bundle for your application.
The 55K BTU outdoor condenser requires a dedicated 208-230V circuit. Each indoor cassette unit requires a separate 208-230V circuit. Consult a licensed electrician for all electrical work.
Yes — each OuttaSight Ceiling Cassette zone operates independently with its own wireless remote and temperature settings. You can also control all zones through the MRCOOL Smart Home app via built-in Wi-Fi.
MRCOOL DIY products include a 7-year compressor warranty and 5-year parts warranty when registered within 30 days of installation. Warranty requires registration at mrcool.com.
The total shipping weight of this complete system is approximately 791.4 lbs (358.96 kg). Freight shipping may be required for larger systems.

Compatible Accessories — Line Sets (Required, Sold Separately)

Each zone requires its own DIY Quick Connect line set. Select the correct size and length for each zone:

SKU Size BTU Range Price Action
DIYLSV25-06-O 1/4" × 3/8" × 25 ft Up to 9K BTU $109.99 View & Add to Cart
DIYLSV25-09-O 1/4" × 3/8" × 25 ft Up to 9K BTU $109.99 View & Add to Cart
DIYLSV25-12-O 1/4" × 3/8" × 25 ft 12K–18K BTU $119.99 View & Add to Cart
DIYLSV50-06-O 1/4" × 3/8" × 50 ft Up to 9K BTU $159.99 View & Add to Cart
DIYLSV50-09-O 1/4" × 3/8" × 50 ft Up to 9K BTU $159.99 View & Add to Cart
DIYLSV50-12-O 1/4" × 3/8" × 50 ft 12K–18K BTU $169.99 View & Add to Cart
DIYLSV75-06-O 1/4" × 3/8" × 75 ft Up to 9K BTU $199.99 View & Add to Cart
DIYLSV75-09-O 1/4" × 3/8" × 75 ft Up to 9K BTU $199.99 View & Add to Cart
DIYLSV75-12-O 1/4" × 3/8" × 75 ft 12K–18K BTU $209.99 View & Add to Cart

Need Help Designing Your Multi-Zone System?

Our HVAC specialists can help you select the right condenser, zone sizes, and line set lengths for your specific application.

Contact Us
?‍?
Why Buy From HVAC PRO Sales? 15+ Years HVAC Experience | 500+ Systems Installed | Authorized MRCOOL Dealer

With over 15 years in the HVAC industry and 500+ MRCOOL systems personally installed, we bring hands-on expertise that translates directly into accurate product guidance. You get the right system the first time — backed by our price match guarantee and free expert support.

500+Systems Installed
15+Years Experience
10yrMRCOOL Warranty
100%Authorized Dealer

Extra Information

Brand:
MRCOOL
Bundle SKU:
HVP-D5-6Z-55K-CC-6-6-6-9-9-9
Series:
MRCOOL DIY 5th Gen
Number of Zones:
6
Total BTU:
45,000 BTU
Zone Configuration:
6K BTU + 6K BTU + 6K BTU + 9K BTU + 9K BTU + 9K BTU
Air Handler Type:
Ceiling Cassette
Condenser SKU:
DIY-MULTI6-55HP230D-O
Refrigerant:
R-454B
Voltage:
208-230V / 1Ph / 60Hz
Total Weight:
795.46 lbs (360.81 kg)
Ordering Guide:
Qty 1: DIY-MULTI6-55HP230D-O; Qty 3: DIYCASSETTE06HP-230D25-O; Qty 3: DIYCASSETTE09HP-230D25-O
SEER2:
Up to 22.0
HSPF2:
Up to 10.0
Warranty:
7-Year Parts & Compressor (DIY) / 5-Year Parts, 7-Year Compressor (Olympus) — Registration Required
