Description
MRCOOL Advantage 5th Gen 36K BTU 230V Condenser — Condenser ONLY
The MRCOOL Advantage 5th Gen 36,000 BTU 230V Condenser delivers powerful, energy-efficient cooling and heating for large residential spaces up to 1,500 sq ft. Engineered with 5th Generation inverter compressor technology, this condenser achieves up to 20 SEER2 efficiency while maintaining quiet operation and consistent comfort even in demanding climates. Sold as Condenser ONLY — pair with a compatible Advantage 5th Gen wall-mount air handler for a complete ductless mini-split system.
Technical Specifications
| Specification | Value |
|---|---|
| Model Number | A-36-HP-C-230D-O |
| Capacity | 36,000 BTU (3 Ton) |
| Efficiency Rating | Up to 20 SEER2 |
| Voltage | 230V / 60Hz / 1-Phase |
| Refrigerant | R-410A |
| Min. Operating Temp (Heating) | 5°F (-15°C) |
| Product Type | Condenser ONLY |
| Series | Advantage 5th Generation |
| Warranty | 7-Year Parts, 7-Year Compressor (registered) |
Product Tips
- Pair correctly: This condenser requires a compatible Advantage 5th Gen wall-mount air handler (sold separately). Match BTU sizes for optimal system performance.
- Professional installation required: The Advantage series uses standard refrigerant connections and requires a certified HVAC technician for installation and refrigerant charging.
- Register your product: Register within 30 days of installation to activate the full 7-year warranty on parts and compressor.
- Electrical requirements: Requires a dedicated 230V circuit. Consult a licensed electrician before installation to ensure proper breaker sizing.
- Line set sizing: Use 3/8" liquid and 5/8" suction line sets for this 36K BTU unit. Maximum line set length is 82 feet.
Frequently Asked Questions
A: This listing is for the Condenser ONLY. You will need to purchase a compatible Advantage 5th Gen 36K BTU wall-mount air handler separately to complete the system.
A: This condenser operates on 230V / 60Hz / 1-Phase power. A dedicated circuit with appropriate breaker is required.
A: R-410A refrigerant. A certified HVAC technician must handle refrigerant charging during installation.
A: MRCOOL provides a 7-year parts and 7-year compressor warranty when the product is registered within 30 days of installation.
A: A 36,000 BTU system is designed for spaces up to approximately 1,400–1,600 sq ft, depending on insulation, ceiling height, and climate zone.
Compatible Accessories
- Advantage 5th Gen 36K BTU Wall-Mount Air Handler (A-36-HP-WMAH-230D-O)
- LineGuard Line Set Cover
- Condenser Wall Mounting Bracket
- MRCOOL Care Kit (annual maintenance)
Need help selecting the right system? Our HVAC experts are ready to assist. Contact us at HVACProSales for personalized guidance on system sizing, installation requirements, and compatible accessories.
Warranty Information
MRCOOL Advantage 5th Gen products include a 7-Year Parts Warranty and 7-Year Compressor Warranty when registered within 30 days of installation. Warranty covers manufacturing defects and component failures under normal use conditions. Labor is not included.
